Precision Elastomers, Inc. Engineering Data

PARTIAL FACILITIES LIST:
Roll Grinding Equipment
Cylindrical Grinders / 12 Total	Lathes / 2nd Operation Machines
1 ea TOS Precision Grinder 12x48 1 ea Summit 12"x72" Precision Grinder 1 ea Myford 5x12 Precision Grinder 2 ea Landis Universal Grinders 12x24 5 ea Brown & Sharp 6x18 Grinders 1 ea Cincinnati 12x36 Precision Grinder	Lablond 12x36 Ciausing: 8x36 & 12x48 Hendey Machine 12x48 Southbend Precision lathe, bed length 8' 4 Harddinge Speed 2" operation lathes 6 ea Dumore Tool Post Grinder
In House Machine / Mold Shop and Secondary Operation Equipment Rubber Molding Machinery	Partial List of Inspection Equipment - Includes:
16 presses up to 250 ton Silicone Dispensing Systems Curing Ovens up to 12' deep Rubber Milling Machines	5" Beam LASERMIKE 183 2" Beam LASERMIKE Genz Optical Comparitor, digital readout Digital Durometer w/SPC software

RUBBER COMPOUNDS & PROPERTIES

	Buty!	EPDM	Hypalon	Natural Rubber	Neoprene (chloroprene)	Nitrine (BUNA-N)	Silicone	Stryne Butadiene (SBP)	Urethane	Fluoro-Elastomer (Viton)
ASTIM D-2000 Classification	AA	BA	CE	AA	BC	BF	GE	AA	BG	HK
Durometer	40-75	30-100	55-95	30-90	30-90	40-95	45-85	40-90	20-100	70-90
Elongation	Fair	Good	Fair	Excel.	Excel.	Good	Fair	Good	Excel.	Good
Heat Aging	Excel.	Excel.	Good	Good	V.Good	Excel.	Excel.	Good	Excel.	Excel.
Sunlight Aging	Good	Excel.	Excel.	Poor	Good	Good	Excel.	Poor	Excel.	Excel.
Lubrivating Oil Resistance	Poor	Poor	Good	Poor	Good	Excel.	Fair	Poor	Good	Good
Aromatic Oil Resistance	Poor	Poor	Poor	Poor	Fair	Good	Poor	Poor	Good	Good
Animal-Vegetable Oils Resistance	Excel.	Poor	Good	Fair	Excel.	Good	Good	Fair	Fair	Good
Flame Resistans	Poor	Poor	Excel.	Poor	Good	Poor	Fair	Poor	Poor	Good
Tear Resistance	Good	Good	Excel.	Good	Good	Fair	Poor	Fair	Excel.	Fair
Abrasion Resistance	Good	Good	Excel.	Excel.	Excel.	Good		Good	Excel.	Fair
Compression Resistance	Fair	Fair	Good	Good	Fair	Good	Fair	Fair	Excel.	Good
Dielectric Strength	Good	Good	Good	Excel.	Fair	Poor	Good	Excel.	Fair	Good
Freedom from Oldor	Good	Fair	Excel.	Excel.	Good	Fair	Fair	Fair	Good	Fair
Maximum Temperature (F°)	250	350	250	210	260	260	550	215	250	500
Minimum Temperature (F°)	-50	-50	-35	-45	-50	-40	-150	-50	-40	-40

• NEOPRENE: All purpose outdoor-indoor synthetic rubber resistant to most chemicals, oils, weathers, etc.	• EPDM: Outdoor weather resistant even under extremely severe conditions - resistant to color fade-heat-electricity.
• NITRILE (Buna-N): Especially resistant to aromatic hydrocarbons, gasoline, petroleum oils, mineral and vegetable oils.	• SBR (Buna-S): Non oil resistant, economically priced synthetic rubber - especially noted for its low water absorption properties .
• NATURAL: Extremely resilient with high tensile & elongation properties - also resistant to flexing, permanent set & electricity - also used as seals in food and beverage applications.	• URETHANE: Outstanding tensile and abrasion qualities - excellent resistance to wear, ozone, oxygen, kerosene & gasoline.
• SILICONES: Can withstand extreme heat or cold and retain flexibility - normal temp. range of -150°F to 550°F	• VITON: In addition to its ability ti with-stand extreme temperatures it is also fuel and oil resistant.

Need something custom made?

What sets us apart is our flexibility to manufacture specialty items which you require for your final assembly. From prototyping to contract manufacturing, our work is of the highest quality, as is our customer service.

Product Development
Machining
Fabrication
Cast urethane parts

Interested? Please let us know how can we help you.
